Twice-per-revolution gas handling with zero oil carryover

Liquid Ring Compressors

Built for reliability, Liquid Ring Compressors deliver stable, oil-free performance even with wet and contaminated gases. Their rugged design and continuous duty capability make them the trusted choice for critical industrial applications.

Up To 6000
M³/Hr Capacity
Max 250
KPaG
100%
Leak-Proof
Our Products
Dry Screw Vacuum Pump - Combined Variable Pitch Technology

Key Features

CNC-built internals & body for very high accuracy

Energy-efficient compressor

Design compliance to API

PLC-operated package with complete instrumentation

Leak-proof package system—ensures no leakages

Rigid, strong casing—rugged in compression

Bearings at both shaft ends

duplex stainless-steel shaft

Robust sealing

Working Principle & Technology

Understanding the Liquid Ring – Pure, Precise, Enduring that delivers 2× Compression, Liquid Ring, Smooth Flow.

Twice-per-revolution gas handling with zero oil carryover

Liquid Ring Compressors

In a liquid ring compressor, the casing is partially filled with sealing liquid. As the impeller rotates, the liquid is centrifuged outward to form a stable liquid ring along the casing wall. Because the impeller is mounted eccentrically, variable compression chambers are created between its blades. Process gas enters through the conical distributor with two suction and two discharge ports. During each revolution, gas is drawn into the suction chambers, compressed as the chamber volume decreases, and then discharged through the outlet ports. This cycle occurs twice per revolution, providing continuous compression.

1

Smooth, vibration-free operation

2

sealing liquid circulation and control systems

3

deliver safe, reliable, and oil-free performance

Dry Screw Vacuum Pump Working Principle

Available Models:

Explore our range of claw vacuum pumps and their performance.

SLC-150

  • Capacity Range: 100 – 200 m³/h

SLC-200

  • Capacity Range: 250 – 400 m³/h

SLC-500

  • Capacity Range: 500 – 750 m³/h

SLC-800

  • Capacity Range: 800 – 950 m³/h

SLC-1000

  • Capacity Range: 1,000 – 1,200 m³/h

SLC-1500

  • Capacity Range: 1,200 – 2,000 m³/h

SLC-2000

  • Capacity Range: 1,800 – 2,600 m³/h

SLC-3000

  • Capacity Range: 2,600 – 3,500 m³/h

SLC-4200

  • Capacity Range: 3,400 – 4,500 m³/h

SLC-5200

  • Capacity Range: 4,500 – 5,400 m³/h

SLC-6200

  • Capacity Range: 5,200 – 6,100 m³/h

Benefits & Advantages

🧪

Handles tough gases

Liquid ring design safely handles saturated, corrosive, or contaminated gas streams without sacrificing performance or compressor life.

⚙️

Non-contact internals

No internal contact between components minimizes wear and reduces heat, vibration, noise, and maintenance.

❄️

Continuous liquid cooling

Cool service liquid removes compression heat and keeps a thermally stable condition for safe compression of hazardous, explosive, or thermally sensitive gases.

🌡️

Near-isothermal

Isothermal-like compression helps the compressor run cooler and maximizes the service life of bearings and seals.

Industrial Applications

Oil-free vacuum solutions for demanding applications requiring contamination-free environments and deep vacuum performance

⚡

Mining & Metallurgy

💊

Fertilizer Plants

⚗️

Oil & Gas Offshore Platforms

⚗️

Chlorine & Vinyl Plants

🔧

Pulp & Paper Industry

Mining & Metallurgy
⚡Mining & Metallurgy
coal mines
ensuring safe operation
stable operation

Ready for Liquid Ring Compressors Technology?

Connect with our engineering experts to discover how Liquid Ring Compressors can enhance your processes with Smooth Flow, Liquid Ring.
