Vacuum Technology

Dry Vacuum Pump With Secondary Suction

Advanced Dry Vacuum Pump designed for negative suction applications requiring medium vacuums such as degassing, exhausting, and pneumatic conveying. MHV series with secondary cooling develops vacuum up to 8000 mmwg with completely dry operation.

Up to 38,000

M³/Hr Capacity

85%

Vacuum Level

100%

Dry Operation

Vacuum Pump with Secondary Suction

Dry Operation

Secondary Cooling

Dual Purpose

Models & Performance (Vacuum)

MODEL	SPEED	500		600		700		800
40 MHV	rpm	Q – m³/hr	BKW	Q – m³/hr	BKW	Q – m³/hr	BKW	Q – m³/hr	BKW
	2985	1806	30.6	1788	37.4	1763	42.9	1745	48.5
	2460	1170	20.7	1158	26.2	1134	31.6	1120	35.9
	1460	768	14.4	750	17.3	726	20.1	708	22.9

500 mbar600 mbar700 mbar800 mbar

Swipe inside the table →

MODEL	SPEED	500		600		700		800
75 MHV	rpm	Q – m³/hr	BKW	Q – m³/hr	BKW	Q – m³/hr	BKW	Q – m³/hr	BKW
	2250	2065	35.8	2030	43	2005	50	1975	58.2
	1850	1638	28.9	1608	34.5	1581	40.2	1554	45.7
	1450	1271	21.6	1241	26.1	1214	30	—	—

500 mbar600 mbar700 mbar800 mbar

Swipe inside the table →

MODEL	SPEED	500		600		700		800
116 MHV	rpm	Q – m³/hr	BKW	Q – m³/hr	BKW	Q – m³/hr	BKW	Q – m³/hr	BKW
	1800	3275	56.4	3220	67.6	3166	77.9	3108	88.2
	1450	2630	45.5	2582	54.1	2538	62.8	2492	71.1
	1200	2090	36.2	2043	44	1998	51	1952	58

500 mbar600 mbar700 mbar800 mbar

Swipe inside the table →

MODEL	SPEED	500		600		700		800
170 MHV	rpm	Q – m³/hr	BKW	Q – m³/hr	BKW	Q – m³/hr	BKW	Q – m³/hr	BKW
	1450	6653	113.4	6538	135	6423	156.7	6308	179
	1200	5174	90.7	5089	108.2	4959	125.4	4869	143
	985	4137	75	4022	89	3922	103	3832	117

500 mbar600 mbar700 mbar800 mbar

Swipe inside the table →

MODEL	SPEED	500		600		700		800
235 MHV	rpm	Q – m³/hr	BKW	Q – m³/hr	BKW	Q – m³/hr	BKW	Q – m³/hr	BKW
	1350	12000	202	11795	239	11665	277	11565	314
	1150	10210	172	10040	203	9930	231	9850	266
	985	8460	143	8280	170	8160	198	8040	225

500 mbar600 mbar700 mbar800 mbar

Swipe inside the table →

Advanced Technology Features

Specialized design elements for superior vacuum performance

Completely Dry Operation

Oil-free operation ensuring clean and contamination-free air handling

100% dry operation

No oil or liquid contact with the air stream, making it ideal for applications requiring clean air or gas handling

Secondary Suction Cooling

Advanced secondary suction system for enhanced cooling performance

Enhanced cooling efficiency

High Vacuum Performance

Develops medium to high vacuum levels for demanding applications

Superior vacuum performance

Dual Application Design

Versatile design suitable for both vacuum and truck blower applications

Multi-purpose versatility

Industrial Applications

Ideal for processes requiring medium vacuums and clean operation

🧪

Degassing Applications

📦

Pneumatic Conveying

🏭

Exhausting Systems

🚛

Truck Blower Systems

⚙️

Process Vacuum

🌱

Environmental Control

Degassing Applications

🧪Degassing Applications

Efficient gas removal

Process optimization

Quality improvement

Need a Custom Vacuum Solution?

Our technical experts will help you select the right Dry Vacuum Pump with secondary suction for your specific application requirements including degassing, exhausting, and pneumatic conveying.
