Swam has legacy of more than 4 decades to serve global market and met customer delight.
Having 05 State of the art manufacturing facilities giving innovative solutions and next generation AI based products to meet client’s Conveying, Boosting & Exhausting requirements.
An ISO 9001: 2015, CE & ATEX Certified Company.
Swam's Vision
Is to provide globally the best-manufactured products. Its focus is on meeting our customers’ requirements while being competitive. Swam sees itself as being recognised as a world leader, providing high-quality robust products.
Swam has achieved this by separating local and international manufacturing facilities. Currently we have 4 factory locations, 2 of which are dedicated for international production. Our 5th (3rd International) factory is currently under construction.
For international projects we only use high profile internationally recognized components. Over the last few years sourcing such products have become easier, due to other global companies undertaking “global manufacturing facilities”, a number of them being produced in India.
Metallurgy
LIme Calcination Plants, Pneumeting Conveying, Oxygen Plants (VPSA), Mixed Gas, Coke over, BF Gas Boosting, Smelting Plants, DRI Plants, Engine Driven emergency blowers.
Industrial
Vacuum Boosting, Oil Free Conveying of Industrial Gases, Vacuum Cleaning & Drying, Fluid Bed Combustion, Super Charging
Chemical & Process Plants
Pneumatic conveying, Handling Corrosive Gases, Gas Boosting, circulation & exhausting, Vacuum Distillation etc.
Water, Waste Water Treatment Plants & Environment Sector
Tank Aeration, Digester Gas Processing, Bio Gas Boosting, Air Sparging, Air Scouring, Vacuum Truck blowers, Mechanical Vapour Re-Compressor
Metallising & Vacuum Degassing
- Object Metallising
- Roll Metallising
- Steel Degassing (VD & VOD)
- Air Evacuation
New Technology Product Launched
Advanced & Next Generation Energy Efficient Helical Blower Package
The Brief about Helical Blower Technology/ Blower type-
Positive Displacement Super Helical lobe Rotary Blower is an integrated package that comprises of high efficiency Helical lobe blowers (which is direct coupled with motor), high efficiency Motors (IE3/IE4) of reputed supplier ABB /SIEMENS /CGL –origin India) & high efficiency VFD (ABB /SIEMENS /Schneider –origin India ) , HMI (Allen bredly –origin India), PLC controls (ABB/Siemens / Allen bredly –origin India), all safety instruments (transmitters & gauges & valves) for reliable and efficient operation (origin India), & fully fail proof design. This package gets accompanied in sound reduction cabinet that ensure low noise level & comply to industrial sound pollution norms for less than 85 Db(A) Noise level @ 1 meter distance.
It has cutting edge technology, next generation,
innovative design, unmatched performance, cent percent
make in India product with low operation Electricity cost
& ownership cost over 15 years.
We offer 5 years smooth & trouble free operation warranty.
Product has 25 years designed life subject to preventive maintenance as per schedule depicted in operation & maintenance manual.
All Electro, mechanical, instrumentation & valves have high efficiency class performance, made in India & complete unit is very robust & heavy duty construction & most reliable.
All components designed to sustain at high ambient temperature & dusty environment without AC Room. Total dependency with Indian vendors at the same time, all components are sturdy , interchangeable & easily available with local sources at optimal cost .Hence very negligible maintenance and less down time & cost saver solution .Besides this easy availability of spare parts & service technician to attend machine components.
Projects Executed by SWAM
- blowers packages for SRU plants
- blowers packages for lime kilns
- mixed gas boosters & gas boosting stations in steel plants
- vacuum system for steel degassing plants
- condenser exhauster package for steam turbines
- turbo blowers / compressors packages
Projects Executed by SWAM
- hydrogen gas conveying and boosting blowers / compressors.
- high pressure gas conveying & boosting blowers / compressors
- high vacuum package for process industries
- ultra high vacuum screw pump packages
- bio gas compressors packages
Why SWAM As Best Choice
SWAM has the most advance manufacturing system with a large number of CNC machines installed in our four plants.
1. ISO-9001-2008 Quality Certified
2. Experience of Over Three Decades
3. An Installation of Over 50000 units World Wide
4. Presence In more than 15 Countries
5. Quality Focus Management
6. Strong Project Management Team
7. Innovation In Design & Development
8. Team of Highly Qualified Professionals
9. Competent Team For Customer Support, Operational
& Maintenance
Product At Glance
Blower Division
Economical and ideal for pneumatic conveying,blending and fluidizing of powdered or granular materials and aeration of liquids.The flow capacities upto 85,000 CMH and pressures upto 1.1 kg/cm2.
The blowers for high suction pressures are with mechanical seals and pressurized lubrication and other design change.
Capacity: Upto 85000 M3/Hr.,
Pressure : Upto 1.1 bar 'g', Vac.- 0.5 bar
Boosters are used for circulation of gases for chemical proocess. The gases handled are Hydrogen, Nitrogen, oxygen, Biogas, Carbon-Di- Oxide, Methance, Mixed Gas, BF Gas, Coke Oven Gas etc. The boosters are fitted with improved Sealing system to make it leak-proof. The mechanical seals are fitted, if application so warrants. The construction materials are special, depending upon the nature of gas.
Capacity : Upto 85000 M3 / Hr.
Pressure : Upto 1.1 bar 'g'
High efficiency Swam Turbo Blowers are most advanced single stage centrifugal machine based on high speed focused specialized technology oil less operation.
Capacity : Upto 21000 M3/H
Super Helical Hybrid Blower are most advanced machine with complete integrated package with VFD Touchscreen, HMI, complete instruments for interlocking and logic control.
It is most suited for SBR based STP operation due to high turn down capability as low as 20% and beneficial for process optimisation and energy saving, whereas other blowers has operational limitation and has 100-60% turndown limit.
Rotary Bio-Gas :- Capacity : Upto 35000 M3 / Hr.
Discharge Pressure : Upto 1.1 bar "g”
Swam bulk vehicle truck blowers have been specifically designed to meet he operating requirements of bulk and silo vehicles in the generation of pressure and loading and unloading of the bulk materials.
SHV SERIES & KHV SERIES
Capacity : Upto 12000 M3 / Hr.
Available in wide range & available in two designs the Rotary lobe type and sliding vane compressors and are available in various MOC’s CI, CS, SS etc. They are available with following parameters.
Rotary Bio-Gas :- Capacity : Upto 12000 M3 / Hr.
Pressure : Upto 1.0 bar "g”
For negative suction, the pumps are ideally suited for processes requiring medium vacuums such as degassing, exhausting and pneumatic conveying. Pumps with secondary cooling (MHV series) develop vacuum upto 8000 mmwg. The operation is completely dry. (Can also be used as Truck Blower Application).
MH.VSERIES & KH.V. Series
Capacity : Upto 38000 M3 / Hr.
Pressure: Upto 85%
A cylindrical rotor turns eccentrically in cylindrical stator of larger diameter. The free space left between stator and rotor is half moon shaped. Some slots are milled in the rotor and stratified plastic blades slide freely in these slots. As rotor rotates due to centrifugal force, blades come out and forced against cylindrical casing, hence create individual cells with reducing volumes during rotation from suction to discharge.
Capacities :- 5100 M3/h
Pressure: - 3.5 bar 'g’
Static pressure upto 1800 mmwg in single stage,Higher static pressure by multi-staging. ID / FD FANS suitable for positive conveying and negative suction. Manufatured out of special materials for Gas conveying and fitted with Mechanical & Semi-mechanical seals.
Capacity : Upto 1,20,000 M3/Hr.
Pressure : Upto 1800 mm WC in single stage
Swam offers its advanced technology, Next Generation SR-Series Blowers, equipped with latest features, enabling it more reliable, energy efficient and lower maintenance. Blowers are ruggedly built appropriate rotor shaft design, aiming at low deflection and sound level The rotor profile of SR-Series are computer generated, enabling better uniform clearance and higher volumetric efficiency The Blowers are readily available for flows upto 1300 M3/hr and pressure upto o.6 kg/cm2
Vaccum Division
Swam dry screw vacuum pumps are designed under SWAM’s unique screw profile engineering to fulfill wide range of chemical and industrial processes. It is operating by rotating a paired screws that efficiently admit gases from inlet into the pump inside and compress through the screw’s swept volume toward the discharge.
Capacity : Upto 3500 M3 / Hr.
Pressure : Upto 0.01 Torr
Swam Liquid Ring Vacuum Compressors and Pumps are rotary machines in which liquid is made to act as a piston. This
liquid is generally water for most of the applications. Hence these are known as Water Ring. A balanced rotor with fixed
radial blades having slight curvature at the tips and a hollow hub revolves in a circular casing containing the liquid. The
axis of rotor is placed eccentric with the axis of casing.
Capacity : Upto 30000 M3 / Hr. to 90% Vacuum
Oil-lubricated rotary vane vacuum pumps are positive-displacement pumps that feature sliding vanes in a rotor rotating within a cavity. An eccentrically mounted rotor with slots rotates in a cylindrical housing and the precisely fitting sliding vanes move in the slots and separate the individual working chambers.
The vacuum boosters in combination with conventional Vacuum mechanical pumps boost high vacuum upto one micron. Ideal for low cost high displacement and vacuum from 50 Torr to one micron.
Capacity : From 500 M3/Hr. to 52000 M3 / Hr.
Pressure : Upto 10-3 Torr in multi stage.
Mechanical Vapour Re Compressor, equipped with latest features, enabling it more reliable, energy efficient and lower maintenance. Blowers/Compressors are ruggedly built appropriate rotor shaft design, aiming at low deflection and sound level The rotor profile are computer generated, enabling better uniform clearance and higher volumetric efficiency They are readily available for flows upto 35,000 M3/hr and pressure upto 1.1 kg/cm2 & Vacuum upto6o%.
Swam offers complete turnkey vacuum system packages with very high vacuums. The system consists of backup pump with vacuum boosters, condensers, gauges, switches, starter panels etc. Thus Swam ready to provide optional total package solution and will deliver package performance as per client requirements. Combination of backup pumps with one booster, two booster, three booster upto five booster with condenser cashpot.
Swam offers advanced design Condenser Exhauster for hogging and holding service in power generation. The system consists of liquid ring vacuum pumps, separator, heat exchanger and ejector (optional) with total recirculation.
Capacity : 10 SCFM , 20 SCFM, 30 SCFM, 40 SCFM
Other Products
Shell & tube type Heat Exchangers are built in a wide variety of sizes and capacities. The Heat Exchangers are fabricated as per TEMA / ASME unfired pressure vessels codes & ASHRAE standard. Heat Exchangers for sea water marine application or with steels shells are also offered and designed as also offered and designed as per customer specific requirement.
Acoustic Enclosure comprises of modular structural frames made out of Steal Plates & Sheets and pre-fabricated sections for high performance acoustic panels. The enclosure is designed acoustically and mechanically to the desired noise level specified by the customer. The thickness of the panel is based on the design requirement.
Project At SWAM
Advanced Manufacturing System
SWAM has the most advance manufacturing system with a large number of CNC machines installed in our four plants. The blowers and other products are manufactured with most optimum profile resulting in higher efficiencies, high displacement, lower slippage. Thus our products are more energy efficient compared to others.
Our Services
Principal Of Operation
1. Swam's philosophy is that whatever the standard is, we have to position ourselves above that standard, not only to meet our own expectations, but also the expectations of our customers. Our focus is one of continued improvement.
2. We experience it once and do it right which helps us to be more efficient while making doing business with Swam a smooth experience.
3. From your Request for Quotation to the product being commissioned, every aspect is fully traceable this extends to our sub-contractors and suppliers, even all of our product castings are supplied to us with its own unique casting number.
4. Swam offers a complete Turn Key service from concept, engineering and design, all the way to manufacturing, testing, installation and commissioning.
5. All of our products have to pass our in-house real-time Hot run testing to a motor size of 1,000Kw for which a performance test certificate is issued as standard.testing station.
The Rotors move opposite to each other, maintaining fine clearances, in perfect synchronization through a set of precision timing gears.
As the rotation proceeds, the trapped air/gas moves along until it reaches the discharge port raising its pressure against the system resistance. The precise clearances within the blower makes
possible the rise in pressure with the least internal slip loss.
The delivery is non pulsating, smooth & with lower sound emission
Client Satisfactory Letters
This is to certify that, we have procured many Rotary Blowers & Mechanical vacuum boosters for MVR Application (vacuum cum Pressure system; from IWs SWAM PNEUMATICS PVT' LTD'' c-2 Sector-3, Noida-201301 (U'P') The performance of these Blowers & Mechanical vacuum boosters supplied is found satisfactory at our clients end and complies with our process requirement.
This is to certify that, we have procured Dry Vacuum Pumps along with Mechanical Vacuum boosters for 10T Vacuum Degassing Operation (VD/VOD), from M/s SWAM PNEUMATICS PVT. LTD., C-2 Sector-3, Noida-201301 (U.P.). The performance of Dry Vacuum pumps & Mechanical vacuum boosters is satisfactory since last 5 years and complies with our process requirement.
This is to certify that, we have procured Dry Vacuum Pumps along with Mechanical Vacuum boosters for Vacuum Degassing Operation (VD/VOD), from M/s SWAM PNEUMATICS PVT. LTD., C-2 Sector-3, Noida-201301 (U.P.).
The performance of Dry Vacuum pumps & Mechanical Vacuum boosters having capacity_9_Tonne supplied Dtd._2 Dec. 2021_ is satisfactory and complies with our process requirement.
